DFN2510 & DF0603 Package ESD Protection Series
DFN2510 & DF0603 Package ESD Protection Series Back
 PDF

Introduction 1、Ultra-thin package shape for miniaturized circuits；
2、4 road protection；
3、It is widely used in electrostatic protection of high transmission rate signal lines；
Features 1.Ultra-low CJ, unidirectional product CJ typical value 0.34pF, bidirectional product CJ typical value 0.22pF, can meet the signal rate requirements above 20GHz
2.Deep flyback characteristics, ultra-low VC, have a better protection against back-end devices, and the back-end devices can choose a wider voltage range
SPECIFICATION

SESDULC1E04P5 SESDULC1E04P5B SESDULC1V5LZB SESDULC3V3LZB SESDULC5V0LZB SESDULC0504P5 SESDULC0504P5B SESDULC3304P5 SESDULC3304P5B
